StruBIM Suite by CYPE
Pricing. There's a free plan to get you started. Pricing is tailored to your team. Reach out to the vendor for a quote. See full pricing · Updated October 14, 2026
StruBIM Suite by CYPE is a Windows structural BIM suite that links IFC-based building models to analytical models, steel and concrete member design, foundation layouts, and drawing production, coordinated through CYPE's BIMserver.center Open BIM workflow.
StruBIM bundles several CYPE applications that share one structural digital thread instead of forcing manual rebuilds between analysis, member design, and documentation teams. IFC Builder introduces or maintains building models, StruBIM Analysis builds and solves a 3D stiffness model, StruBIM Design sizes members and generates reinforcement or steel checks, and StruBIM Foundations extends the same data into pad and pile cap detailing.
CYPE documents spatial analysis with bar, shell, and finite-element discretization plus automatic wind load generation aligned with ASCE 7-10 within the analysis module descriptions (CYPE StruBIM Suite page, 2026). Designers can inspect displacements, reactions, contour maps, and then push approved results downstream without retyping forces.
Design modules cite checks against ACI 318 editions for reinforced concrete and ANSI/AISC 360-10 for steel sections, including composite columns and punching shear around flat plates. Drawings such as column and beam schedules export with the level of detail expected for engineer-of-record packages, subject to each country's localization settings.
Licensing mixes free tiers for analysis or foundations with paid Pro and Expert levels that unlock fuller detailing scopes. Because the suite depends on BIMserver.center for collaboration, confirm cloud connectivity, data residency, and partner access rules before you promise owners a fully openBIM delivery.
Specifications
Pricing
Platforms
Used for
Used by
Tasks
Pros and cons
Pros
- Keeps analysis, design, and drawing data in one CYPE ecosystem
- Strong code references for US-oriented concrete and steel checks
- Open BIM positioning reduces proprietary lock-in when paired with IFC sources
- Free entry tiers help students and small firms test workflows
Cons
- Heavy reliance on BIMserver.center for multi-party workflows
- Regional code packs still need verification outside CYPE's default catalogs
- Mixed free and paid modules can confuse license planning
- Marketing sites mix HTTP microsites that may require careful bookmarking
Key features
IFC-centric workflow: Import or author IFC4 models and keep coordination on BIMserver.center according to CYPE's Open BIM guidance.
StruBIM Analysis: Build analytical models with load cases, diaphragms, shells, and automated ASCE 7-10 wind patterns.
StruBIM Design: Size concrete and steel members, edit reinforcement, and regenerate drawing schedules tied to the structural model.
Punching shear tools: Check slab-column transfers with critical perimeter logic embedded in the design module.
StruBIM Foundations: Lay out pad footings and pile caps using reactions imported from the solved analytical model.
Versioned licensing: Mix free analysis or foundation tiers with Pro and Expert packages for fuller documentation output.
Pricing
StruBIM free modules
per month
Free
StruBIM Analysis Free, Design Free, and Foundations Free on the CYPE versions page. Ask about download rules before install.
StruBIM Pro or Expert
Contact sales
Design and Foundations also come in Pro and Expert. No public price on the versions page. Ask CYPE or a distributor.
Prices come from each vendor’s public listings and can change. Double-check the current price on the vendor site before you buy.
Frequently asked questions
Can StruBIM import models from Revit?
Yes via IFC exchange, as highlighted in CYPE training videos that start from Revit exports. Always validate geolocation, shared coordinates, and analytical simplifications after import.
What analysis engine does StruBIM use?
Documentation describes a 3D stiffness matrix approach with bar and shell finite elements, supporting diaphragms, boundary edits, and result visualization before exporting to design modules.
Which design codes are referenced?
Marketing copy cites ACI 318-14/11/08 for reinforced concrete checks and ANSI/AISC 360-10 for hot-rolled and hollow steel sections. Confirm local amendments with your licensed engineer.
Is there a free version?
CYPE lists free variants for analysis, design, and foundations alongside paid Pro and Expert levels. Feature matrices live on the StruBIM versions page; expect export and detailing limits on free builds.
How does BIMserver.center fit in?
CYPE positions BIMserver.center as the Open BIM hub that synchronizes StruBIM data with other CYPE tools and external IFC contributors. Treat it like a project server with its own access controls.
Does StruBIM handle foundations?
StruBIM Foundations designs pad footings and pile caps using column and wall reactions from the solved model, with drawing output for plan views and schedules. Deep geotechnical coupling may still need specialist software.
